AB burner

  • Part Code
  • Model
    AB-45
  • Outer diameter A mm
    145
  • Inner diameter B mm
    52
  • Thickness C mm
    30
  • Mixture inlet D mm
    Rp3/8”
  • Power kw
    6
This product cannot be returned or replaced without quality problem. Please refer to the policy of "7 Days without Reason for Return or Replacement" for details
Expected delivery：
If the payment is completed before 16:00 on working days, the goods can be delivered on the same day; The payment will be completed after 16:00 working day, and the goods will be delivered the next day; It will be postponed in case of holidays
Delivery：

选择省份

    Freight：
    Unknown
    Price：
    $
    Quantity：
    - +
    Add Cart
    Buy now

    A total of 0 products were selected
    Batch add to cart
    Alternative products
    Product Introduction
    Product Manual
    Product Overview

    "AB ring burner is a fully premixed burner for air and gas. The whole body of the burner is made of aluminum alloy. During combustion， a stable rigid annular flame is produced， and the power adjustment ratio is wide. AB ring burners are mainly used for surface treatment of pipes. The pipe surface uses an annular high-temperature flame to remove stress and improve the surface gloss of the product. Processing product diameter: 4-32mm Product speed: 0-120m/min Product surface temperature: up to 120℃ Applicable fuel: methane or propane"

    Click to view：AB Ring Burner
