Home >Products >Pressure regulator&Filter >Pressure regulator >Single Stage pressure regulator >Gas pressure regulator

RPGR-C Series Pressure Regulating Valve

  • Part Code
    1010604310-002
  • Model
    RPGR-C 1065（3-7kPa）
  • Connection size
    DN 65
  • Maximum inlet pressure
    100KPa
  • Outlet pressure range
    3-7kPa
  • Connection type
    Flange
This product cannot be returned or replaced without quality problem. Please refer to the policy of "7 Days without Reason for Return or Replacement" for details
Expected delivery：
If the payment is completed before 16:00 on working days, the goods can be delivered on the same day; The payment will be completed after 16:00 working day, and the goods will be delivered the next day; It will be postponed in case of holidays
Delivery：

选择省份

    Freight：
    Unknown
    Price：
    $
    Stock：
    4
    Quantity：
    - +
    Add Cart
    Buy now

    A total of 0 products were selected
    Batch add to cart
    Alternative products
    Product Introduction
    Product Manual
    Q&A
    Product Overview

    弹簧压力_画板 1.jpgRPGR-C Series Pressure Regulating Valve_页面_1.jpg

    Click to view：RPGR-C Series Pressure Regulating Valve




    Q：Accuracy level？

    A：AC10(±10%). AC5,AC15,AC20 are available upon request.


    Q：Close pressure level？

    A：SG30%. SG10%, SG20% are available upon request.


    Q：What media are the flow curves in the catalogue?

    A：Air and natural gas media, other media need to be converted.


    Q：What are the main parameters to be provided for product selection?

    A：Medium, outlet pressure, inlet pressure, flow rate.


    Q：Installation requirements?

    A：Do not block the openings.
